Jazlyn Studio Garage Apartment

© Copyright by designer/architect      Drawings and photos may vary slightly. Refer to the floor plan for accurate layout.


PROJECT PLAN #593-009D-7531

tab green left curve Quick Details tab green right curve
  • 342 Total Square Feet
  • 1st Floor 342
  • Width: 17'-0" Depth: 27'-0"
  • 1 Bedrooms
  • 1 Full Bath
  • Door 1: 9x7
  • Standard Foundation - Slab
tab green left curve Additional Options tab green right curve

Save this plan to:

Share on Facebook Tweet this on Twitter Pin this on Pinterest Recommend on Google Add to Stumbleupon Digg It! Share on LinkedIn Share on Tumblr

tab green left curve Special Features tab green right curve
  • Building height - 22'-5"
  • Roof pitches - 4/12, 8.5/12
  • Ceiling heights -
  • First floor - 8'
  • Second floor - 8'
  • 9' x 7' overhead door
  • The first floor consists of a 1-car garage, laundry room, mechanical closet and an entry with door to the outside and stair to second floor
  • The second floor features a studio apartment complete with a well-equipped kitchenette alcove, closet and private bath
  • Complete list of materials

First Floor

Image Of Large First Floor For House Plan 009D-7531

Second Floor

Image Of Second Floor For House Plan 009D-7531
